Drilling Spindles

High torque motorized spindles with high axial stiffness to absorb the large forces in drilling applications.

PDF Brochure

MFW-820

Diameter80 mm
Tool InterfaceHSK-E32
Max. Speed20'000 rpm
Bearing LubricationGrease
Power (kW) S1 / S67.5 / 8.6 kW
Torque (Nm) S1 / S64.0 / 4.6 nM

MFW-1206/20

Diameter120 mm
Tool InterfaceHSK-A40
Max. Speed20'000 rpm
Bearing LubricationGrease
Power (kW) S1 / S69.50 / 14.03 kW
Torque (Nm) S1 / S615.10 / 22.30 Nm

MFW-1216/20

Diameter120 mm
Tool InterfaceHSK-A40
Max. Speed20'000 rpm
Bearing LubricationGrease
Power (kW) S1 / S617.00 / 35.18 kW
Torque (Nm) S1 / S610.10 / 20.90 Nm

MFW-1309/24

Diameter130 mm
Tool InterfaceHSK-E50
Max. Speed24'000 rpm
Bearing LubricationGrease
Power (kW) S1 / S627.30 / 35.49 kW
Torque (Nm) S1 / S629.00 / 37.70 Nm
